Elster R1200 Irrigation Meter

The R1200 is a paddle wheel irrigation water meter designed to
withstand harsh agricultural conditions and comply with strict
European standards.

It is the latest range of irrigation meters from Elster. Unlike a Woltmann
meter, the paddle wheel rotor is located out of the main flow stream.
This allows the free passage of water, reducing the risk of jamming and
damage from stones and other suspended solids that are common in
irrigation water. The unconstricted cross-section also delivers a lower
pressure loss than a Woltmann meter.

Features

  • Paddle wheel design for unhindered flow
  • Long-lasting, wear-resistant materials
  • Tamper-proof dry dial register (IP68)
  • Removable mechanism for easy maintenance
  • Suitable for horizontal and vertical installation
  • Optional Reed switch single pulser
  • Maximum operating temperature: 30°C. Operation guaranteed up to 50 °C
  • Nominal pressure (PN): 10 or 16 bar
  • Approved to the latest European
    Directive 2004/22/EC

Standards

  • 2004/22/EC
  • IP68



Part Number Description Size Quantity
41541-00 R1200 Meter, Table ‘D’ raised flanges x 200mm long 50mm

41543-00 R1200 Meter, Table ‘D’ raised flanges x 225mm long 80mm

41544-00 R1200 Meter, Table ‘D’ raised flanges x 250mm long 100mm
